Screw Press Separator
Supplier Details
Australian Waste Engineering
Company Name
Australian Waste Engineering
Postal Address
RSD 6600 Mount Gambier
State
SA
Country
Australia
Postcode
5290
Equipment Details
Make, Model & Classification
Name
Screw Press Separator
Model
FAN PSS1.2-520 Separator
Classification
Dehydration/Dewatering/Desiccation
Material Types
Food Organics, Other Organics (garden etc.), Other Recyclable
Operations
Description
Dewatering of Thick (20% solids) as well as Thin slurries (down to 0.1%solids) with dryness adjustable between 25% and 55% (depending on application and model). Ideal for waste products washed out in a liquid stream.
Operating Principles
The PSS is fed by pump or gravity from a holding tank. It is also possible to feed the PSS by hopper. The optimal feeding method depends on the raw material consistency and the site conditions. In the slotted screen, the fibrous solids are screened out from the liquid. The fibers build up a layer which also acts as a filter to separate finer particles from the liquid. The auger flights convey this layer to the solids outlet. The screen surface is cleaned and a new filter layer is formed. The dryness of the solid cake can be adjusted by the number and position of the weights.
Product Attachments
No attachment available
